SRT Servo T06 1/10 Offroad HV WATERPROOF (0.10s/7.4V/2.8kg) Digital (small size)

SRT Servo T06 1/10 Offroad HV WATERPROOF (0.10s/7.4V/2.8kg) Digital (small size)

SKU T06
von SRT
CHF 22.00 - CHF 22.00
CHF 22.00
CHF 22.00 - CHF 22.00
CHF 22.00

Versandinformation

Produkte mit Status "auf Lager", werden bei Bestellungen bis 14.00 Uhr Nachmittags, noch am selben Tag versendet.

Information

Bei Fragen zum Produkt oder detaillierter Informationen zum Bestellvorgang. Ruf uns an!

Telefon: +41 44 500 84 66

Email: support@rcxx.shop

SRT Servo T06 1/10 Offroad HV WATERPROOF (0.10s/7.4V/2.8kg) Digital (small size)

KEY FEATURES

& Ideal for 1/10 on road and 1/10 off road scale applications
& incredible efficiency and low power consumption
& Superior waterproof
& 1-Year Limited Warranty

Item no 4.8V 6.0V 7.4V Gear Motor Case Dimension
(mm)		 Weight
(g)
Speed:
sec/60°		 Torque:
kg-cm/oz-in		 Speed:
sec/60°		 Torque:
kg-cm/oz-in		 Speed:
sec/60°		 Torque:
kg-cm/oz-in
T06HV  0.16 1.9/26.4 0.12 2.5/34.7 0.10 2.8/38.9  Copper & Alu DC Plastic 22.5*12.5*24.0 16.0


Application :

 1/10  Off-road         1/10  Off-road       Electric/ BOAT



PRODUCT SPECIFICATIONS

Type: Digital
Bearing: Dual
Motor Type: DC
Gear Type: Metal
Gear Material: Copper & Alu
control system: pulse width control
working frequence: 1520μs / 330hz
operating voltage: dc4.8-7.4v
operating temperature range: -10 to + 60 degree
operating speed (4.8v): 0.16 sec/60 degrees at no load
operating speed (6.0v): 0.12 sec/60 degrees at no load
operating speed (7.4v): 0.10 sec/60 degrees at no load
stall torque (4.8v): 1.9kg.cm (26.4 oz/in)
stall torque (6.0v): 2.5kg.cm (34.7 oz/in)
stall torque (7.4v): 2.8kg.cm (38.9 oz/in)
potentiometer drive: direct drive
dimensions: 22.5x12.5x24.0 mm /0.89x0.49x0.94 in
weight: 16.0g (0.56 oz)
connector wire length: jr 350 mm

}
